FEHLING FAT DRAG BAR 1 1/4 Zoll, 3LL

Description

Handlebar Fat Drag Bar 1 1/4 inch / 1 inch for chopper and cruiser of the premium brand FEHLING
High-quality handlebar, top processed and great shaped. The optimized seating position, coupled with good steering behavior, whether on highways at high speed or on winding roads provide high driving pleasure and good guidance of the machine.
– Set off at the ends of the handles and in the clamping area to 1 inch
– 3-hole internal cable routing
– Color: Black or chrome
– With parts approval in accordance with § 19 para. 3
3 hole internal cable guide:
– Each 1 slot 13 x 30 mm in the cable notch in the area of the handles
– 1 slot 13 x 40 mm centered in the area of the clamping
Dimensions:
a = Width: 820 mm
c = Depth: 120 mm
e = Bottom center: 300 mm
Ø Tube = 1 1/4 inch (31.75)
Ø Handle ends = 1 inch (25.4 mm)
Length handle ends approx. 204 mm
Scope of delivery: 1 piece
Note:
Accessory handlebars are shipped without holes for locking the switch units, as these are positioned differently depending on the motorcycle model.
The drilling of the handlebar is allowed. To do this, align the new handlebar on the vehicle. Now mount the switch units for testing and note the clearance to the tank at full steering angle.
We recommend to use the drilling template for a good result.
